Bambu Lab H2S Laser Full Combo
1.899,00€ ME ΦΠΑ
Availability: In Stock
SKU:
H2SLASERCOMBO
Bambu Lab H2S Laser Full Combo στη 3DHUB Greece! O 3D printer που αλλάζει τα δεδομένα στο personal manufacturing τώρα με αυξημένο μέγεθος και ταχύτητα! Eπικοινωνήστε μαζί μας για πληροφορίες και demo στο κεντρικό μας lab στην Αθήνα!
Ο νέος Bambulab H2S Laser Full Combo εγκαινιάζει μια νέα σειρά προϊόντων που ενσωματώνουν καινοτομίες και χαρακτηριστικά για να αναβαθμίσετε το hobby σας σε μια μικρή μονάδα παραγωγής!
The Bambu Lab H2S Combo is a complete package combining the advanced H2S 3D printer with the integrated AMS 2 Pro system for automatic filament management. This makes it ready for multi-material printing straight out of the box while ensuring high precision, secure network connectivity, and a clean working environment.
Key Features
-
Product Features
- 340*320*340 mm³ Print Volume
- Multi-color 3D Printing
- Closed-loop Servo Motor Extruder
- Optional 10W Laser and Cutting Module
- 5μm Resolution Optical Motion Calibration
- 350°C Nozzle & 65°C Active Chamber Heating
- Full Filament Path AI Detection
- Voltage Range: 200-240V
Η 3DHUB GREECE είναι ο μεγαλύτερος επίσημος αντιπρόσωπος της Bambulab στην Ελλάδα με εξαιρετικό τοπικό support και στοκ σε ανταλλακτικά! Αποτελεί την ασφαλέστερη επιλογή σας καθώς έχει ήδη εγκατεστημένη βάση με πάνω από 4000! Bambu εκτυπωτές !!! και φυσικά λειτουργεί το πληρέστερο 3D print/scan εργαστήριο στα Βαλκάνια με πάνω από 10 χρόνια εμπειρίας! Δείτε ΕΔΩ το VIDEO και επισκευθείτε μας να δείτε πάνω από 30x Bambu printers σε λειτουργία!
Άμεση Διαθεσιμότητα!
Bambu Lab H2S Laser Full Combo στη 3DHUB Greece!
Cut. Engrave. Draw.
Compact. Capable. All in One.
Live Spatial Alignment
Top-down BirdsEye camera⁽⁸⁾ and onboard toolhead camera enable Live Spatial Alignment, letting you preview the toolpath directly on your material with 0.3 mm accuracy. What you see is what you get.
Auto Arrangement
Bambu Suite automatically arranges your project shapes to make the most of every sheet—smart, efficient, and effortless.
10W 455nm Laser Power
Slice through up to 5 mm plywood, acrylic, or PU with ease—clean, fast, and precise.
Air Assist
Air Assist keeps your lines crisp by blowing away smoke and char while cooling the surface—preventing soot buildup and beam distortion for sharp, clean results.
Digital Cutting
Effortlessly cut through paper, vinyl, PU leatherette, and more—clean, accurate, and ready to apply.
Drawing
Use the drawing module to automate linework, sketches, or handwritten notes—precise, repeatable, and hands-free.
Not a Toolkit.
Bambu Lab H2S – Technical Specifications
Body
| Build Volume (W*D*H) | 340*320*340 mm³ |
| Chassis | Aluminum, Steel, Plastic and Glass |
| Laser Safety Windows | Equipped on Laser Edition, normal H2S can upgrade through Laser Upgrade Kit |
| Air Assist Pump | Equipped on Laser Edition, normal H2S can upgrade through Laser Upgrade Kit |
Physical Dimensions
| Physical Dimensions | 492*514*626 mm³ |
| Net Weight | H2S: 30 kg H2S Laser Edition: 30.5 kg |
Toolhead
| Hotend | All Metal |
| Extruder Gear | Hardened Steel |
| Nozzle | Hardened Steel |
| Max Nozzle Temperature | 350 ℃ |
| Included Nozzle Diameter | 0.4 mm |
| Supported Nozzle Diameter | 0.2 mm, 0.4 mm, 0.6 mm, 0.8 mm |
| Filament Cutter | Built-in |
| Filament Diameter | 1.75 mm |
| Extruder Motor | Bambu Lab High-precision Permanent Magnet Synchronous Motor |
Heatbed
| Supported Build Plate Type | Textured PEI plate, Smooth PEI Plate |
| Max Heatbed Temperature | 120 ℃ |
Speed
| Max Speed of Toolhead | 1000 mm/s |
| Max Acceleration of Toolhead | 20,000 mm/s² |
| Max Flow for Hotend (Standard Flow Hotend) | 40 mm³/s (Test parameters: 250 mm round model with a single outer wall; Bambu Lab ABS; 280 ℃ printing temperature) |
| Max Flow for Hotend (Optional High Flow Hotend) | 65 mm³/s (Test parameters: 250 mm round model with a single outer wall; Bambu Lab ABS; 280 ℃ printing temperature) |
Chamber Temperature Control
| Active Chamber Heating | Supported |
| Max Temperature | 65 ℃ |
Air Purification
| Pre-filter Grade | G3 |
| HEPA Filter Grade | H12 |
| Activated Carbon Filter Type | Granulated Coconut Shell |
| VOC Filtration | Superior |
| Particulate Matter Filtration | Supported |
Cooling
| Part Cooling Fan | Closed Loop Control |
| Cooling Fan for Hotend | Closed Loop Control |
| Main Control Board Fan | Closed Loop Control |
| Chamber Exhaust Fan | Closed Loop Control |
| Chamber Heat Circulation Fan | Closed Loop Control |
| Auxiliary Part Cooling Fan | Closed Loop Control |
Filament Supported
| PLA, PETG, TPU, PVA, BVOH, ABS, ASA, PC, PA, PET, PPS; Carbon/Glass Fiber Reinforced PLA, PETG, PA, PET, PC, ABS, ASA, PPA, PPS |
Sensor
| Live View Camera | Built-in; 1920*1080 |
| Toolhead Camera | Built-in; 1600*1200 |
| BirdsEye Camera | Built-in; 3264*2448 (Equipped with Laser Edition) |
| Door Sensor | Supported |
| Filament Run Out Sensor | Supported |
| Filament Tangle Sensor | Supported |
| Filament Odometry | Supported with AMS |
| Power Loss Recovery | Supported |
Electrical Requirements
| Voltage | 100–120 VAC / 200–240 VAC, 50/60 Hz |
| Max Power¹ | 2050 W@220 V / 1170 W@110 V |
Working Temperature
10 ℃-30 ℃
Electronics
| Touchscreen | 5-inch 720*1280 Touchscreen |
| Storage | Built-in 8 GB EMMC and USB Port |
| Control Interface | Touchscreen, mobile App, PC App |
| Neural Processing Unit | 2 TOPS |
Software
| Slicer | Bambu Studio Supports third-party slicers which export standard G-code, such as Super Slicer, PrusaSlicer and Cura, but certain advanced features may not be supported. |
| Supported Operating System | MacOS, Windows, Linux |
Wi-Fi
| Operating Frequency | 2412-2472 MHz (CE/FCC), 2400-2483.5 MHz (SRRC) 5150-5850 MHz |
| Wi-Fi Transmitter Power (EIRP) | 2.4 GHz: <23 dBm (FCC); <20 dBm (CE/SRRC/MIC) 5 GHz Band1/2: <23 dBm (FCC/CE/SRRC/MIC) 5 GHz Band3: <30 dBm (CE); <24 dBm (FCC) 5 GHz Band4: <23 dBm (FCC/SRRC); <14 dBm (CE) |
| Wi-Fi Protocol | IEEE 802.11 a/b/g/n |
10W Laser Module
| Laser Type | Semiconductor Laser |
| Laser Wavelength | Engraving Laser: 455 nm ± 5 nm Blue Light Height Measuring Laser: 850 nm ± 5 nm Infrared Light |
| Laser Power | 10 W ± 1 W |
| Laser Spot Dimension | 0.03 * 0.14 mm² |
| Working Temperature | 0 ℃–35 ℃ |
| Max Engraving Speed | 400 mm/s |
| Max Cutting Thickness | 5 mm (Basswood Plywood) |
| Laser Safety Class for Laser Module | Class 4 |
| Overall Laser Safety Class² | Class 1 |
| Engraving Area | H2D: 310 * 270 mm² H2S: 310 * 260 mm² |
| XY Positioning Method | Visual Positioning |
| XY Positioning Accuracy | < 0.3 mm |
| Z Height Measuring Method | Micro Lidar |
| Z Height Measuring Accuracy | ± 0.1 mm |
| Flame Detection | Supported |
| Temperature Detection | Supported |
| Door Sensor | Supported |
| Laser Module Installation Detection | Supported |
| Safety Key | Included |
| Air Pump | Built-in; 30 kPa, 30 L/min |
| Ventilation Pipe Adapter Outer Diameter | 100 mm |
| Supported Material Type | Wood, rubber, metal sheet, leather, dark acrylic, stone, and more |
Cutting Module
| Cutting Area | H2D：300*285 mm² H2S：297.5*300 mm² |
| Drawing Area | 300*255 mm² |
| Supported Pen Diameter | 10.5 mm–12.5 mm |
| Cutting Mat Type | LightGrip and StrongGrip Cutting Mats |
| Blade Type | 45°*0.35 mm |
| Blade Pressure Range | 50 gf–600 gf |
| Max Cutting Thickness | 0.5 mm |
| Blade and Pen Recognition | Supported |
| Cutting Mat Type Detection | Supported |
| Supported Image Type | Bitmap and Vector Images |
| Supported Material Type | Paper, PVC, vinyl, leather, and more |
| ¹ To ensure the heatbed quickly reaches the needed temperature, the printer will maintain maximum power for about 3 minutes. | ||
| ² When the printer’s protection is complete and properly working, the printer and laser module work as a class 1 laser product. |
Additional information
| Weight | 12 kg |
|---|
