XYZ 3D Scanner

239,90 ME ΦΠΑ



Capture physical objects with high detail accuracy using XYZPrinting’s portable, cost-effective, high-resolution 3D scanner 2.0. Furthermore, the second and optimized version of the very popular 3D scanner also allows the export into several popular 3D file formats.
The main product features:

NEW V2 Version!
  • Portable, cost-effective and high-resolution 3D scanner
  • Use in an working range of 20 – 120 cm; optimal is 25-60 cm
  • 3D-Scan small and large objects easily and quickly
  • Export your 3D data to .stl, .obj, .ply or .fbx



Παράδοση σε 3-4 ημέρες

Κωδικός προϊόντος: XYZ3DSCANNER Κατηγορία:

Περιγραφή

XYZPrinting 3D Scanner 2.0 – 3D Scanning in a New Dimension

Capture physical objects with high detail accuracy using XYZPrinting’s portable, cost-effective, high-resolution 3D scanner 2.0. Furthermore, the second and optimized version of the very popular 3D scanner also allows the export into several popular 3D file formats.

XYZPrinting 3D-Scanner 2.0 – The main product features:

  • Portable, cost-effective and high-resolution 3D scanner
  • Work in an ideal working range of 20 – 120 cm; optimal is 25-60 cm
  • 3D-Scan small and large objects easily and quickly
  • Export your 3D data to .stl, .obj, .ply or .fbx

Real sense, real power

The XYZprinting 3D Scanner 2.0 is based on the Intel® RealSense™ module. 3D scan and process your 3D scans very quickly. Ideally, you should work with this 3D scanner in a working area of 25-60 cm. This 3D scanner has a large scanning range of 20-120 cm. This gives you the freedom to easily capture both large and small objects. With the colour camera, which achieves up to 1920x1080p at 40fps, you can scan 3D much faster.

Multiple export formats

Quickly create your 3D models and 3D prints. Supports multiple export formats such as stl, obj, ply, and fbx to quickly create workable 3D models for 3D game development, VR, and AR demos.

Share your world in 3D online

Capture your product, model or historical artifact in high resolution and share it online in Sketchfab or XYZPrinting’s online 3D gallery. Communicate visually better with your customers and audiences.

Edit your 3D models with XYZscan mobile phone

Use XYZScan Handy – a 3D scanning and post-processing software – to easily edit your 3D models after 3D scanning. Quickly cut out unwanted areas of your model or make the colors of your models stand out more.

Swiftly Take On the World

Share Your Scans Across Different Mediums

Scan and Print

Turn your physical world into digital replicas, where you can modify them, and then reproduce them with 3D printing. Need to replace that broken part that you can’t find in stores? Want to make a gift for someone but don’t know how to 3D model it? Simply scan the desired objects to recreate them in different sizes or change it completely to create new ones.

How It Works

Scanning Properties:

Scan Engine
Intel® RealSense™ Camera
Scan Size (WxDXH)
5 x 5 x 5 ~ 100 x 100 x 200 cm
Scan Resolution
0.2 ~ 1.5 mm
Depth Image Size
640 x 480 at 30 fps
Color Image Size
Up to 1920 x 1080p at 40fps
Operating Range
25 ~ 60 cm
Scan Software
XYZscan Handy
Output File Types
For PC: .obj, .ply, .stl, .fbx
For Mac: .obj, .ply, .stl

Hardware:

Connectivity
USB 3.0 Cable

System Requirements

Operating Systems
Windows 10 (64 bits)
MAC OS X 10.10, 10.11, 10.12, 10.13
Minimum Hardware Requirements
For PC: CPU: 4th Generation Intel® Core™ i5 Processor or more / RAM: 4GB RAM or more
For Mac: CPU: 4th Generation Intel® Core™ i5 Processor and above / RAM: 4GB RAM or more / GPU: Intel HD Graphics 4000 / VRAM: 2G
For MacBook Pro (Early 2013), iMac (Early 2013) and newer
Note: MacBook, MacBook Air, or Mac Mini are not supported.
Recommended Hardware
GPU: NVIDIA GeForce GTX 750 ti (or more) with 2G VRAM (Desktop) NVIDIA GeForce GTX 840 m (or more) with 2G VRAM (Laptop)
Note: Devices with Intel® RealSense™ Scan module built-in are not supported. Windows Surface Tablets are not supported.

Size & Weight

Product Dimensions (WxDxH)
41 x 157 x 61 mm
Product Weight
238 g
Packed Dimensions (WxDxH)
110 x 94 x 214 mm
Packed Weight
382 g
